The large inclination conveyor belt is composed of baseband, retaining edge and diaphragm. The retainingedge plays the role of preventing materials from sliding and falling. In order to bypass the drum, the retaining edge is designed into a corrugated shape; The diaphragm is used to support materials. In order to realize large inclination transportation, T-type TC type is adopted.
